html如何实现球体旋转
HTML中，通过CSS设置球体元素的
border-radius为50%使其呈圆形，再利用
transform-style: preserve-3d和
animation属性结合关键帧动画实现旋转
HTML中实现球体旋转，可以通过多种方法来实现,以下是几种常见的实现方式及其详细步骤：
使用CSS3和HTML实现简单球体旋转
创建HTML结构
创建一个基本的HTML结构，用于展示旋转的球体，可以使用一个<div>元素来代表球体。
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">Rotating Sphere</title>
<link rel="stylesheet" href="styles.css">
</head>
<body>
<div class="sphere"></div>
<script src="script.js"></script>
</body>
</html>
编写CSS样式
使用CSS3来设置球体的外观和旋转动画，通过border-radius属性将<div>元素变为圆形，并使用@keyframes定义旋转动画。
body {
display: flex;
justify-content: center;
align-items: center;
height: 100vh;
background-color: #f0f0f0;
}
.sphere {
width: 100px;
height: 100px;
background: radial-gradient(circle, #ff0000 0%, #ff7f00 30%, #ffff00 50%, #7fff00 70%, #00ff00 100%);
border-radius: 50%;
animation: rotate 4s infinite linear;
}
@keyframes rotate {
from {
transform: rotateX(0) rotateY(0);
}
to {
transform: rotateX(360deg) rotateY(360deg);
}
}
使用JavaScript控制动画（可选）
虽然CSS3的动画已经能够实现旋转效果，但有时可能需要使用JavaScript来控制动画,例如在用户交互时暂停或启动动画。
document.addEventListener('DOMContentLoaded', () => {
const sphere = document.querySelector('.sphere');
sphere.addEventListener('click', () => {
if (sphere.style.animationPlayState === 'paused') {
sphere.style.animationPlayState = 'running';
} else {
sphere.style.animationPlayState = 'paused';
}
});
});
使用WebGL实现更复杂的3D球体旋转
对于需要更高性能和更复杂效果的场景，可以使用WebGL来实现3D球体旋转，WebGL允许在HTML中渲染3D图形,并结合JavaScript来实现动态效果。
创建HTML和CSS基础结构
创建一个基本的HTML文件和CSS文件,用于包含WebGL画布。
<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8">
<meta name="viewport" content="width=device-width, initial-scale=1.0">WebGL Rotating Sphere</title>
<link rel="stylesheet" href="styles.css">
</head>
<body>
<canvas id="glcanvas" width="600" height="400"></canvas>
<script src="script.js"></script>
</body>
</html>
body {
display: flex;
justify-content: center;
align-items: center;
height: 100vh;
background-color: #f0f0f0;
}
canvas {
border: 1px solid white;
}
初始化WebGL上下文并创建球体几何结构
在JavaScript中，初始化WebGL上下文,并定义球体的顶点和索引。
const canvas = document.getElementById('glcanvas');
const gl = canvas.getContext('webgl') || canvas.getContext('experimental-webgl');
if (!gl) {
alert('Unable to initialize WebGL. Your browser may not support it.');
}
gl.clearColor(0.0, 0.0, 0.0, 1.0);
gl.clear(gl.COLOR_BUFFER_BIT);
function createSphere(radius, latitudeBands, longitudeBands) {
let vertices = [];
let indices = [];
for (let latNumber = 0; latNumber <= latitudeBands; latNumber++) {
let theta = latNumber Math.PI / latitudeBands;
let sinTheta = Math.sin(theta);
let cosTheta = Math.cos(theta);
for (let longNumber = 0; longNumber <= longitudeBands; longNumber++) {
let phi = longNumber 2 Math.PI / longitudeBands;
let sinPhi = Math.sin(phi);
let cosPhi = Math.cos(phi);
let x = cosPhi sinTheta;
let y = cosTheta;
let z = sinPhi sinTheta;
let u = 1 (longNumber / longitudeBands);
let v = 1 (latNumber / latitudeBands);
vertices.push(radius x);
vertices.push(radius y);
vertices.push(radius z);
}
}
for (let latNumber = 0; latNumber < latitudeBands; latNumber++) {
for (let longNumber = 0; longNumber < longitudeBands; longNumber++) {
let first = (latNumber (longitudeBands + 1)) + longNumber;
let second = first + longitudeBands + 1;
indices.push(first);
indices.push(second);
indices.push(first + 1);
indices.push(second);
indices.push(second + 1);
indices.push(first + 1);
}
}
return {
vertices: new Float32Array(vertices),
indices: new Uint16Array(indices)
};
}
const sphere = createSphere(1, 30, 30);
创建WebGL着色器并渲染球体
编写顶点着色器和片段着色器，并将它们链接到WebGL程序中，将球体的顶点和索引数据上传到WebGL缓冲区,并绘制球体。
const vertexShaderSource = `
attribute vec3 aVertexPosition;
uniform mat4 uModelViewMatrix;
uniform mat4 uProjectionMatrix;
void main(void) {
gl_Position = uProjectionMatrix uModelViewMatrix vec4(aVertexPosition, 1.0);
}
`;
const fragmentShaderSource = `
void main(void) {
gl_FragColor = vec4(1.0, 1.0, 1.0, 1.0);
}
`;
function compileShader(gl, source, type) {
const shader = gl.createShader(type);
gl.shaderSource(shader, source);
gl.compileShader(shader);
if (!gl.getShaderParameter(shader, gl.COMPILE_STATUS)) {
console.error('An error occurred compiling the shaders: ' + gl.getShaderInfoLog(shader));
gl.deleteShader(shader);
return null;
}
return shader;
}
const vertexShader = compileShader(gl, vertexShaderSource, gl.VERTEX_SHADER);
const fragmentShader = compileShader(gl, fragmentShaderSource, gl.FRAGMENT_SHADER);
const shaderProgram = gl.createProgram();
gl.attachShader(shaderProgram, vertexShader);
gl.attachShader(shaderProgram, fragmentShader);
gl.linkProgram(shaderProgram);
if (!gl.getProgramParameter(shaderProgram, gl.LINK_STATUS)) {
console.error('Unable to initialize the shader program: ' + gl.getProgramInfoLog(shaderProgram));
}
gl.useProgram(shaderProgram);
const vertexPositionAttribute = gl.getAttribLocation(shaderProgram, 'aVertexPosition');
gl.enableVertexAttribArray(vertexPositionAttribute);
const uModelViewMatrix = gl.getUniformLocation(shaderProgram, 'uModelViewMatrix');
const uProjectionMatrix = gl.getUniformLocation(shaderProgram, 'uProjectionMatrix');
const vertexBuffer = gl.createBuffer();
gl.bindBuffer(gl.ARRAY_BUFFER, vertexBuffer);
gl.bufferData(gl.ARRAY_BUFFER, sphere.vertices, gl.STATIC_DRAW);
const indexBuffer = gl.createBuffer();
gl.bindBuffer(gl.ELEMENT_ARRAY_BUFFER, indexBuffer);
gl.bufferData(gl.ELEMENT_ARRAY_BUFFER, sphere.indices, gl.STATIC_DRAW);
使用Canvas和JavaScript实现球体旋转
对于需要更多控制或更复杂交互的场景，可以使用Canvas和JavaScript来实现球体旋转，这种方法允许逐帧绘制球体,并实现更复杂的动画效果。
获取Canvas元素和设置初始参数
获取Canvas元素，并根据设备的DPI进行缩放，定义一些全局变量，包括Canvas的宽度、高度、球体旋转的角度和存储所有点的数组。
const canvas = document.querySelector('#scene');
canvas.width = canvas.clientWidth;
canvas.height = canvas.clientHeight;
const ctx = canvas.getContext('2d');
if (window.devicePixelRatio > 1) {
canvas.width = canvas.clientWidth 2;
canvas.height = canvas.clientHeight 2;
ctx.scale(2, 2);
}
let width = canvas.clientWidth;
let height = canvas.clientHeight;
let rotation = 0;
let dots = [];
定义点类和创建球体函数
定义一个Dot类，表示球体上的每个点的属性和方法，编写createDots函数来生成一定数量的点,并分别标记为不同的颜色。
class Dot {
constructor(x, y, z, color) {
this.x = x;
this.y = y;
this.z = z;
this.color = color;
this.xProject = 0;
this.yProject = 0;
this.sizeProjection = 0;
}
project(sin, cos) {
const rotX = cos this.x + sin (this.z GLOBE_CENTER_Z);
const rotZ = -sin this.x + cos (this.z GLOBE_CENTER_Z) + GLOBE_CENTER_Z;
this.sizeProjection = FIELD_OF_VIEW / (FIELD_OF_VIEW rotZ);
this.xProject = (rotX this.sizeProjection) + PROJECTION_CENTER_X;
this.yProject = (this.y this.sizeProjection) + PROJECTION_CENTER_Y;
}
draw(sin, cos) {
this.project(sin, cos);
ctx.beginPath();
ctx.arc(this.xProject, this.yProject, DOT_RADIUS this.sizeProjection, 0, Math.PI 2);
ctx.fillStyle = this.color;
ctx.closePath();
ctx.fill();
}
